It has the characteristics of simple operation and strong practicability, and is
It has the characteristics of simple operation and strong practicability, and is widely used in logistics transportation and cargo loading. It plays an important role in urban and rural transportation.
Model | Orchard electric freight tricycle |
Container quantity | CKD 80sets/40HQ SKD110sets/40HQ |
Vehicle size (length*width*height) | Not marked |
Standard voltage | 60 v |
Controller | 12 tube controller |
Battery Type | Lead acid battery |
Load capacity | 500kg |
Vehicle quality | 180kg (Without battery) |
Front shock absorber | Spring damping composite shock absorber |
Rear shock absorption | Steel plate shock absorption |
Rear axle | 130# |
Carriage structure | Car parts are detachable and easy to assemble |
Car size | 1400*1050 mm |
Tire specifications | Tire 300-12 |
Traveling motor power | 650w |
Speed | 35km/h |
Battery capacity | 60v 32ah |
Cruising range | 45km |
Wheelbase | 1830 mm |
Wheelbase | 860mm |
Braking method | Foot brake mechanical parking brake |
Minimum ground clearance | 170mm |
Lamps | Headlight + turn signal + driving light + reversing light |
