It has the characteristics of simple operation and strong practicability, and is
It has the characteristics of simple operation and strong practicability, and is widely used in logistics transportation and cargo loading. It plays an important role in urban and rural transportation.
Model | 1.3m cargo tricycle |
Container quantity | CKD75sets/40HQ SKD 55sets/40HQ |
Vehicle size (length*width*height) | 2700*900*1300mm |
Standard voltage | 72v |
Controller | 18 tube controller |
Battery Type | Lead acid battery |
Load capacity | 600kg |
Vehicle quality | 195kg(Without battery) |
Front shock absorber | Spring damping composite shock absorber |
Rear shock absorption | Steel plate shock absorption |
Rear axle | 130# |
Carriage structure | Car parts are detachable and easy to assemble |
Car size | CKD75sets/40HQ SKD 55sets/40HQ |
Tire specifications | Front tire 350-12, Rear tire 375-12 |
Traveling motor power | 1000w |
Speed | 42km/h |
Battery capacity | 72v/32ah |
Cruising range | 60km |
Wheelbase | 1830mm |
Wheelbase | 860mm |
Braking method | Foot brake mechanical parking brake |
Minimum ground clearance | 160mm |
Lamps | Headlight + turn signal + driving light + reversing light |
